AAA Trailers Tri Axle Tag Trailer in Adelaide

Overview: Tri Axle Tag Trailer

Big loads demand a trailer that can handle the weight, track straight, and keep everything under control from hook-up to drop-off. The AAA Trailers Tri Axle Tag Trailer is built to spread the strain evenly across three axles, giving you stability and protecting your gear on Adelaide freight runs, cross-country hauls, or rugged site work. Ideal for shifting heavy plant, oversized machinery, and multi-tonne loads, it’s engineered to perform day in and day out.


A high-tensile steel chassis and 5mm forklift-rated chequer plate floor give it the strength to take on punishing conditions. Underneath, K-Hitch 22.5” drum brake axles, FUWA FW520 8-leaf spring suspension, and an EBS multi-volt braking system combine for reliable handling and stopping power, even when fully loaded.


Standard inclusions feature a pintle hook coupling, C-channel coaming with tie rails, integrated tie-down points, alloy quarter guards, dual steel toolboxes with stainless T-handles, and 12V electric bi-fold ramps with N150 battery and Anderson plug.


For operators who want a setup built their way, options such as lay-flat ramps, hub odometers, custom paint finishes, flashing beacons, and spare wheels let you match the trailer to your exact work requirements, whether in metro Adelaide or on the long haul.

Backed by 12-Month Warranty

28T

ATM

20T

GTM

10.9m

Length

SPECIFICATIONS

Category Details
ruler with arrow

Dimensions & Capacity

ATM: 28T

GTM: 20T

Tare Weight: Approx. 7T

Total Length: 10.9m

Deck: 8.74m
steel beam

Construction & Frame

Mainframe: High-tensile steel grade

Floor: 5mm steel chequer plate, forklift-rated

Coupling: Pintle hook

Coaming: C-channel with tie rail

Tie-down Points: Integrated into the floor
shaft

Axles, Suspension & Braking

Axles: K-Hitch 22.5” drum brake axles

Suspension: K-Hitch tri-axle FUWA FW520 8-leaf spring

Landing Legs: K-Hitch 2-speed

Brake Kit: EBS multi-volt 12/24V

Spare Wheel Carrier: Single (spare wheel optional)
wheel

Wheels & Tyres

Wheels: 10/285 PCD dual steel rims (aluminium optional)

Tyres: 255/70R22.5
electric sign

Electrical, Lighting & Safety

Lighting: Full LED

Mudguards: Alloy quarter guards front and rear with AAA Trailers mudflaps

Hub Odometer: Optional

Hard-Wired Flashing Beacon: Optional
magnifying glass with letter 'i' on it

Onboard Equipment

Toolboxes: 2 steel with stainless steel “T” handles
ramp

Ramps

Bi-Fold Ramps:

12V electric power pack

N150 battery with built-in Anderson plug
gate

Gates & Load Handling

Container Pins: 20ft
document wtih gear and pen

Optional Extras

Custom Paint - Coaming Rails

Hard Wired Flashing Beacon

Hub Odometer

Spare Wheel: Steel or Alloy

Get Your Tag Trailer in Adelaide Today

Whether you’ve got questions, want to run through the specs, or need a hand choosing the right setup, our team is ready to help you get moving.

What They Say About Our Truck Trailers

Why Choose AAA Tag Trailers in Adelaide?

Built for Equipment Haulage

Ideal for transporting excavators, rollers, and a variety of machinery.

Easy Loading Access

Beavertail design with durable bi-fold ramps makes loading straightforward.

Compact Yet Capable

Offered in tandem or tri-axle setups with high ATM ratings.

Industry Trusted

Relied on by councils, utilities, and civil contractors across Adelaide and beyond.

Custom Options

Choose from paint finishes, coaming rails, and load restraint systems to suit your needs.

Frequently Asked Questions

  • Are the tag trailers new or used?

    Each Tri Axle Tag Trailer we deliver in Adelaide and across Australia is built brand new, with no prior work history. From the first weld through to final inspection, skilled tradespeople follow strict quality controls before putting every unit through performance testing. When it arrives in your yard, it’s ready to start earning immediately and built to handle years of hard work on the road.

  • Do you offer financing options for your tag trailers?

    Yes. We provide finance options to get your Tri Axle Tag Trailer into operation without holding up your workload. You can choose from one of our competitive options or work with your own broker, who can arrange an inspection before purchase for added reassurance. The process is kept quick and straightforward so you can focus on moving freight instead of chasing admin.

  • Can I customise the specifications of the tag trailer I order?

    Absolutely. From complimentary paint finishes to a range of optional gear suited to your freight profile and working conditions, we can build your trailer to match your exact requirements. Custom-built units take longer to deliver than stock models, but you’ll receive equipment built to slot seamlessly into your operation.

  • Do you have a warranty policy for your tag trailers?

    Yes. Every Tri Axle Tag Trailer comes with a 12-month warranty that covers defects in workmanship or materials under normal operating conditions. If a fault appears during that time, we’ll organise repairs or a replacement promptly. It’s our commitment to stand behind every trailer we produce, giving you confidence in every haul.

  • What are the delivery times for ordered tag trailers?

    We regularly have stock in Adelaide ready for immediate pickup or fast nationwide delivery. For new builds, the standard lead time is up to three months from deposit, allowing us to maintain consistent quality and produce a trailer you can depend on for the long term.

  • Do you provide after-sales service and support?

    Yes. Our relationship with you continues after handover. We offer operational advice, help arrange servicing, and respond to technical queries. Our goal is to keep your Tri Axle Tag Trailer performing at its best so your schedules stay on track without costly interruptions.
