AAA Trailers – Flat Top Refrigerated Trailer - 22 Pallet in Sydney

Overview: Flat Top Refrigerated Trailer - 22 Pallet

The AAA Trailers – Flat Top Refrigerated Trailer (22 Pallet) is purpose-built for linehaul and temperature-controlled freight. It offers the reliability and performance you need to transport refrigerated goods across Australian conditions. At 13.72m in length with a tare weight of 9.3 tonnes and a 47-tonne ATM, it delivers strong payload capacity while keeping goods at the right temperature with a Thermo King unit of your choice in single or dual-zone configuration.


The high-tensile steel mainframe, HD extruded duct aluminium floor, and insulated aluminium panel walls provide strength and thermal efficiency, while K-Hitch tri-axle airbag suspension, 22.5” drum brake axles, and a multi-volt EBS brake kit ensure safe, stable transport. Standard features include loading bars for double stacking pallets, LED lighting, stainless steel water tank, and toolboxes, with optional extras available to suit specific freight operations.

Backed by 12-Month Warranty

Flat Top Refrigerated Trailer - 22 Pallet

47T

ATM

23.5T

GTM

13.72m

Length

SPECIFICATIONS

Category Details
ruler with arrow

Dimensions & Capacity

ATM: 47T

GTM: 23.5T

Tare Weight: Approx. 9.3T

Total Length: 13.72m
steel beam

Construction & Frame

Mainframe: High-tensile steel grade

Floor: HD Extruded Duct Aluminium Floor

Walls: Aluminium Panel with Polvurethane Insulation

Side Wall Insulation: 45mm

Roof, Floor, Front Wall Insulation: 100mm

Rear Door Insulation: 76mm

Loading Bars: Loading bars for double stacking pallets

Kingpin: Dual-position 50mm bolt-in (90mm optional)
shaft

Axles, Suspension & Braking

Axles: K-Hitch 22.5” drum brake axles

Suspension: K-Hitch tri-axle airbag (FUWA FW520 8-leaf spring optional)

Landing Legs: K-Hitch 2-speed

Brake Kit: EBS multi-volt 12/24V

Spare Wheel Carrier: Dual (spare wheels optional)
wheel

Wheels & Tyres

Wheels: 10/285 PCD dual steel rims (aluminium optional)

Tyres: 11R22.5
electric sign

Electrical, Lighting & Safety

Lighting: Full LED

Mudguards: Plastic radius guards with AAA Trailers mudflaps, quarter guards front and rear
snowflake

Refrigeration Unit

Refrigerated Unit: Thermo King Unit of Choice

Configuration: Single Zone/Dual Zone
magnifying glass with letter 'i' on it

Onboard Equiptment

Toolboxes: Steel with stainless steel “T” handles for storing loading bars

Water Tank: 30L stainless steel
document wtih gear and pen

Optional Extras

Road train bracket, coupling, air and electrical

Get Your Refrigerated Trailer in Sydney Today

We’d love to help you find the refrigerated trailer that’s the perfect fit for your transport needs. Our friendly staff is easy to talk to and ready to give you clear, helpful advice to make the process simple.

What They Say About Our Truck Trailers

Why AAA Trailers for Your Next Refrigerated Trailer in Sydney?

Maximum Thermal Performance

Insulated panels and quality seals to ensure stable cold chain transport.

Australian Spec Build

High-tensile steel frame and heavy-duty aluminium flooring built for long service life.

Durable Flooring

Aluminium or steel floors built to handle pallet jacks and forklifts.

Temperature Versatility

Compatible with a wide range of fridge units for frozen or chilled goods.

Flexible Trailer Options

Lead or B-trailer formats available to suit your transport fleet.

Frequently Asked Questions

  • Are the trailers new or used?

    We only sell brand-new refrigerated trailers. Each unit is assembled and fully tested by our technicians before handover in Sydney.

  • Do you offer financing options for truck trailers?

    Yes. Competitive finance options are available, and you’re welcome to have your own broker inspect the trailer before you sign off.

  • Can I customise the specifications of the trailers I order?

    You can choose a custom colour at no extra cost. Just note that custom builds take a little longer than stock units because they’re built from the ground up.

  • Do you have a warranty policy for your truck trailers?

    Every trailer includes a 12-month warranty covering defects in materials and workmanship under normal use. If a fault appears in that period, we’ll repair or replace the affected part.

  • What are the delivery times for ordered trailers?

    Many models are ready to go. If we’re building to order, allow up to three months from your deposit.

  • Do you provide after-sales service and support?

    Yes. Our team is here for questions, advice, and servicing whenever you need a hand.
