Curtainsider – Drop Deck - B Trailer 22 Pallet in Melbourne

Overview: Curtainsider – Drop Deck - B Trailer 22 Pallet

When it comes to handling serious freight volumes, this 22-pallet drop deck B-trailer combines heavy-duty construction with the load flexibility transport operators need. The high-tensile steel frame, forklift-rated 5mm chequer plate floor, and C-channel coaming with tie rail provide the strength to stand up to daily linehaul work and interstate runs.


Riding on K-Hitch tri-axle airbag suspension with 22.5” drum brake axles and a multi-volt EBS braking system, it delivers stable handling and reliable stopping power across freight corridors across Melbourne, throughout Victoria and anywhere in Australia.


It comes standard with load-restraint curtains, hanging aluminium side gates, stainless steel toolboxes, LED lighting, dual spare wheel carriers, and a stainless water tank. Optional extras, such as road train kits, ring feeders, and custom curtains, allow you to configure it to your fleet’s needs.

Backed by 12-Month Warranty

47T

ATM

23.5T

GTM

13.8m

Length

SPECIFICATIONS

Category Details
ruler with arrow

Capacity & Dimensions

ATM: 47T

GTM: 23.5T

Tare Weight: Approx. 10.5T

Total Length: 13.8m
steel beam

Construction & Frame

Mainframe: High-tensile steel grade

Floor: 5mm steel chequer plate, forklift-rated

Kingpin: Dual-position 50mm bolt-in (90mm optional)

Coaming: C-channel with tie rail
shaft

Axles, Suspension & Wheels

Axles: K-Hitch 22.5” drum brake axles

Suspension: K-Hitch tri-axle airbag

Landing Legs: K-Hitch 2-speed

Wheels: 10/285 PCD dual steel rims (aluminium optional)

Tyres: 255/70R22.5

Spare Wheel Carrier: Dual (spare wheels optional)
electric sign

Lighting & Electrical

Lighting: Full LED

Brake Kit: EBS multi-volt 12/24V
magnifying glass with letter 'i' on it

Standard Equipment

Gates: Side gate pockets with hanging aluminium side gates

Water Tank: 30L stainless steel

Toolboxes: 2 steel with stainless steel “T” handles

Mudguards: Plastic radius guards with AAA Trailers mudflaps

Curtains: Polyweld load restraint, single base colour
document wtih gear and pen

Optional Extras

Road train kit

Ring feeder

Custom paint – coaming rails

Road train / long vehicle signs

Hub odometer

Spare wheel: steel or alloy

Custom curtains – to be quoted

Get Your Drop Deck Curtainsider Trailer in Melbourne Today

Talk to our Melbourne team about your drop deck curtainsider trailer needs and we’ll help you find the right fit for your operations. We’re with you from the first quote to the moment your trailer is ready to roll.

What They Say About Our Truck Trailers

Why AAA Trailers for Your Next Drop Deck Curtainsider Trailer in Melbourne?

12-Month Warranty

All drop decks come with a full 12-month warranty for peace of mind.

Tough Construction

Built with high-tensile steel and forklift-rated flooring for long-lasting strength.

Ready for Australian Roads

Fitted with quality components and tested suspension to handle harsh conditions.

Flexible Ramp Choices

Options include bi-fold, slide-out, or fold-down ramps with diesel or electric operation.

Reliable Support

Backed by a responsive team that’s ready to assist when you need it.

Frequently Asked Questions

  • Are the trailers new or used?

    Every Curtainsider – Drop Deck-B Trailer 22 Pallet we supply is built brand new, never reconditioned or second-hand. Each trailer goes through a careful build process, complete inspection, and performance testing so it’s ready to start work as soon as it arrives.

  • Do you offer financing options for truck trailers?

    Yes. We offer a range of competitive finance options for the Curtainsider – Drop Deck-B Trailer 22 Pallet, making it easier to expand your fleet without tying up working capital. You can also have your preferred finance broker inspect the trailer before you proceed.

  • Can I customise the specifications of the trailers I order?

    Yes, you can. We offer free custom paint finishes and a variety of optional extras to suit your freight operations. Just keep in mind that a made-to-order build will take longer to deliver than stock units already available.

  • Do you have a warranty policy for your truck trailers?

    Each Curtainsider – Drop Deck-B Trailer 22 Pallet comes with a 12-month warranty that covers defects in materials and workmanship under normal use. If any issue occurs, we’ll arrange repairs or part replacements to get you moving again quickly.

  • What are the delivery times for ordered trailers?

    Some Curtainsider – Drop Deck-B Trailer 22 Pallet units may be ready for faster dispatch across Victoria and anywhere in Australia. If your trailer requires a new build, allow up to three months from when your deposit is received.

  • Do you provide after-sales service and support?

    Yes. Our team is available to provide guidance, technical advice, and assistance with arranging servicing to keep your Curtainsider – Drop Deck-B Trailer 22 Pallet operating reliably on freight runs across Victoria and throughout the country.
