AAA Trailers 45’ Drop Deck Extendable With Bi-Fold Ramps in Melbourne

Overview: Drop Deck Extendable With Bi-Fold Ramps

When the load doesn’t fit the standard, this 45’ Drop Deck Extendable with Bi-Fold Ramps steps in. Built to stretch from 13.72m to 19.5m, it’s made for shifting machinery, containers, and long structural freight without compromising stability or compliance.


The high-tensile steel frame and forklift-rated 5mm chequer plate floor bring serious strength to the job, while the dual-position kingpin adds flexibility for different haul setups. K-Hitch tri-axle airbag suspension and a multi-volt EBS braking system keep handling smooth and predictable, even under heavy payloads on demanding routes.


Standard features include 3-way container pins, a 1,200mm steel front gate, stainless steel toolboxes, LED lighting, and a dual spare wheel carrier. Bi-fold ramps run on a 12V electric pack for quick, controlled loading, with optional slide-out or flip-over neck ramps available for specialist jobs.


Ideal for Melbourne operators running freight along busy interstate corridors, regional supply runs, or construction haulage across Victoria and beyond, it’s ready to be set up with extras like road train kits, ring feeders, oversize signage, hub odometers, or custom paint.

Backed by 12-Month Warranty

47T

ATM

27T

GTM

13.72m

CL

19.5m

EL

SPECIFICATIONS

Category Details
ruler with arrow

Dimensions & Capacity

ATM: 47T

GTM: 27T

Tare Weight: Approx. 11.7T – 12.5T

Total Length (Closed): 13.72m

Lower Deck (Closed): 9.4m

Upper Deck: 3.95m

Extended Length: 19.5m
steel beam

Construction & Frame

Mainframe: High-tensile steel grade

Floor: 5mm steel chequer plate, forklift-rated

Coaming: 5-inch with tie rail

Kingpin: Dual-position 50mm bolt-in (90mm optional)
shaft

Axles, Suspension & Braking

Axles: K-Hitch 22.5”, 19.5” or 17.5” drum brake axles

Suspension: K-Hitch tri-axle airbag (FUWA FW520 8-leaf spring optional)

Landing Legs: 10/285, 8/275 or 10/275 PCD dual steel rims (aluminium optional)

Brake Kit: 255/70R22.5, 260/70R19.5 or 235/75R17.5

Spare Wheel Carrier: Dual (spare wheels optional)
wheel

Wheels & Tyres

Wheels: 10/285, 8/275 or 10/275 PCD dual steel rims (aluminium optional)

Tyres: 255/70R22.5, 260/70R19.5 or 235/75R17.5
electric sign

Electrical, Lighting & Safety

Lighting: Full LED

Road Train Bracket: Coupling, air, and electrical (optional)

Mudguards: Quarter guards front and rear with AAA Trailers mud flaps

Hub Odometer: Optional

Hard-Wired Flashing Beacon: Optional
magnifying glass with letter 'i' on it

Onboard Equipment

Toolboxes: 2 steel with stainless steel “T” handles

Water Tank: 30L stainless steel
ramp

Ramps

Standard Bi-Fold Ramps:

12V electric power pack

N150 battery with built-in Anderson plug

Optional Ramp Configurations:

Slide-out upper deck neck ramps

Flip-over neck ramps

3-piece flip-over upper deck ramps

No ramps
gate

Gates & Load Handling

Front Gate: 1,200mm steel

Side Gates: Side gate pockets (side gates and gate carrier optional)

Container Pins: 3-way
document wtih gear and pen

Optional Extras

Road Train Kit

Ring Feeder

Side Gates

Custom Paint - Coaming Rails

Forward Fold Ramp Option

Hard Wired Flashing Beacon

Oversize Signs

Hub Odometer

Spare Wheel: Steel or Alloy

Get Your Drop Deck Trailer in Melbourne Today

Talk to our Melbourne team about your drop deck trailer needs and we’ll help you find the right fit for your operations. We’re with you from the first quote to the moment your trailer is ready to roll.

What They Say About Our Truck Trailers

Why Choose AAA Trailers Drop Decks in Melbourne?

12-Month Warranty

All drop decks come with a full 12-month warranty for peace of mind.

Tough Construction

Built with high-tensile steel and forklift-rated flooring for long-lasting strength.

Ready for Australian Roads

Fitted with quality components and tested suspension to handle harsh conditions.

Flexible Ramp Choices

Options include bi-fold, slide-out, or fold-down ramps with diesel or electric operation.

Reliable Support

Backed by a responsive team that’s ready to assist when you need it.

Frequently Asked Questions

  • Are the trailers new or used?

    All 45’ Drop Deck Extendable trailers we supply are brand new, never second-hand or reconditioned. Each one is built by our experienced Melbourne team, undergoes a complete quality inspection, and is tested to confirm it’s work-ready before handover.

  • Do you offer financing options for truck trailers?

    Yes. We provide flexible, competitive finance options for the 45’ Drop Deck Extendable, giving you the ability to grow your fleet without tying up working capital. If you’d like, you can also involve your own broker to inspect the trailer before making a decision.

  • Can I customise the specifications of the trailers I order?

    Absolutely. You can choose your preferred paint finish at no extra charge and add from a range of upgrades to suit your freight tasks. Just keep in mind, a made-to-order unit will require extra build time compared to stock trailers already in Melbourne.

  • Do you have a warranty policy for your truck trailers?

    Every 45’ Drop Deck Extendable comes with a 12-month warranty that covers any defects in materials or workmanship under standard operating conditions. Should an issue arise, we’ll arrange prompt repairs or part replacements to keep you moving.

  • What are the delivery times for ordered trailers?

    We sometimes have ready-built 45’ Drop Deck Extendables available for immediate delivery throughout Melbourne and Victoria. If your order requires a new build, the usual turnaround time is up to three months from deposit payment.

  • Do you provide after-sales service and support?

    Yes. Our team offers ongoing assistance long after the sale, including maintenance scheduling, technical guidance, and servicing support to keep your 45’ Drop Deck Extendable performing reliably on freight runs across Victoria and anywhere in Australia.
