AAA Trailers – Flat Top Refrigerated Trailer - 22 Pallet in Adelaide

Overview: Flat Top Refrigerated Trailer - 22 Pallet

Got temperature-sensitive freight that can’t miss delivery windows? The AAA 22-pallet Flat Top Refrigerated Trailer is built for Adelaide operators shifting fresh produce, chilled goods, or frozen loads across metro runs, regional hauls, and interstate corridors. With a 47-tonne ATM, around 9.3-tonne tare, and a 13.72 m deck, it offers serious payload while keeping cargo at the right temp from depot to drop-off. The Thermo King unit runs in single or dual-zone mode, perfect for mixed-temperature consignments.


A high-tensile steel chassis, insulated aluminium panel walls, and heavy-duty extruded aluminium duct floor safeguard load quality while handling the daily grind of linehaul and back-to-back deliveries.


On the blacktop, K-Hitch tri-axle airbag suspension, 22.5” drum brake axles, and a multi-volt EBS braking system deliver predictable handling and strong, compliant braking, whether you’re pulling up in Adelaide or running long to the east coast.


Factory-fit gear includes pallet loading bars for double stacking, LED lights, a stainless water tank, and toolboxes, making it ready for work from day one. Add optional extras to fine-tune it to your freight mix and keep high-value loads moving efficiently anywhere in Australia.

Backed by 12-Month Warranty

47T

ATM

23.5T

GTM

13.72m

Length

SPECIFICATIONS

Category Details
ruler with arrow

Capacity & Dimensions

ATM: 47T

GTM: 23.5T

Tare Weight: Approx. 9.3T

Length: 13.72m
snowflake

Refrigeration System

Refrigerated Unit: Thermo King unit of choice

Zone Options: Single Zone / Dual Zone
steel beam

Construction & Frame

Mainframe: High-tensile steel grade

Floor: HD extruded duct aluminium floor
walls

Walls & Insulation

Panels: Aluminium panel with polyurethane insulation

Side Wall Insulation: 45mm

Roof, Floor, Front Wall Insulation: 100mm

Rear Door Insulation: 76mm
box

Load Handling & Equipment

Loading Bars: For double-stacking pallets
shaft

Axles, Suspension & Wheels

Axles: K-Hitch 22.5” drum brake axles

Suspension: K-Hitch tri-axle airbag

Landing Legs: K-Hitch 2-speed

Wheels: 10/285 PCD dual steel rims (aluminium optional)

Tyres: 11R22.5

Spare Wheel Carrier: Dual (spare wheels optional)
electric sign

Brake & Electrical Systems

Brake Kit: EBS multi-volt 12/24V

Lighting: Full LED
magnifying glass with letter 'i' on it

Onboard Equiptment

Water Tank: 30L stainless steel

Toolboxes: Steel with stainless steel “T” handles for storing loading bars

Mudguards:

Plastic radius guards with AAA Trailers mudflaps

Quarter guards front and rear
document wtih gear and pen

Optional Extras

Road train bracket: Coupling, air and electrical

Get Your Flat Deck Trailer in Adelaide Today

Looking for the right flat deck trailer for your work? We’re here to make it easy. Contact us for honest advice, a competitive price, and a trailer that’s ready to get the job done across Adelaide and beyond. If you’ve got questions or need a hand working out the best option for your freight, our friendly team is only a call or message away.

What They Say About Our Truck Trailers

Why AAA Trailers for Your Next Flat Deck Trailer in Adelaide?

Maximum Cooling Efficiency

Polyurethane-insulated walls, roof, floor, and doors maintain consistent temperatures.

Durable Build

High-tensile steel frame and heavy-duty aluminium flooring built for long service life.

Loading Versatility

Fitted with loading bars for double stacking and smooth pallet handling.

Refrigeration Compatibility

Suitable for Thermo King single or dual-zone refrigeration systems.

Operator-Friendly Design

Equipped with K-Hitch running gear, EBS brakes, LED lighting, toolboxes, and water tanks.

Frequently Asked Questions

  • Are the flat deck trailers new or used?

    Every Flat Top Refrigerated Trailer we supply is completely new and work-ready from the moment it leaves our yard. Each unit is assembled and carefully inspected by our skilled team before handover, so you’re not simply purchasing equipment, you’re receiving a trailer prepared for the jobs ahead. With a fresh build, every weld, ramp, and fitting is untouched and has never been subjected to the wear and tear of heavy use before reaching you.

  • Do you offer financing options for your flat deck trailers in Adelaide?

    Yes. We have competitive finance packages available for the Flat Top Refrigerated Trailer. If you prefer to go through your own broker, they can arrange an inspection before you commit to purchase. This way, you can be confident you’re getting a trailer that meets your expectations for both quality and value. We aim to keep the buying process simple, transparent, and stress-free for operators in Adelaide.

  • Can I customise the specifications of the flat deck trailers I order?

    Certainly. You can choose a custom paint colour at no extra cost and select from a range of optional extras to suit your operational requirements. Custom-built trailers will take longer than stock units, as they are constructed from the ground up to meet your exact needs. The end result will be a trailer built for your business, not a generic off-the-shelf choice.

  • Do you have a warranty policy for your flat deck trailers?

    Every Flat Top Refrigerated Trailer – 22 Pallet is covered by a 12-month warranty against defects in materials or workmanship under standard operating conditions. If a fault occurs, we arrange swift repairs or part replacements to keep you operational.

  • What are the delivery times for ordered flat deck trailers in Adelaide?

    We regularly have trailers available for prompt delivery in Adelaide, so you could be on the road sooner than you expect. If your trailer needs to be built, the usual turnaround is up to three months from deposit. This timeframe allows us to maintain high build standards without rushing. This helps ensure your trailer is ready for years of hard work.

  • Do you provide after-sales service and support?

    Yes. Our team continues to provide assistance well after delivery, from operational tips to organising servicing, to keep your trailer in peak condition. We remain committed to supporting you long-term because a reliable trailer keeps your business running smoothly.
